- Wide module compatibility: 16A MPPT current, suitable for high-power PV modules
- Intelligent energy allocation: dynamic phase balancing to reduce grid dependence
- Heavy-load management: supports up to 200% overload in off-grid mode
- Integrated active safety: AFCI and temperature detection on PV and battery connectors
- Battery-ready design: natively compatible with LUNA2000 S0 and S1 systems
- Whole-home backup: continuous emergency power supply via SmartGuard-63A-T0
- Outdoor-ready design: robust enclosure with IP66 protection rating
- PV input voltage: max 1,100 V
- MPPT operating range: 160–1,000 V
- Number of MPPTs: 2
- Battery compatibility: LUNA2000-5/10/15-S0 and LUNA2000-7/14/21-S1
- Battery voltage range: 600–980 V
- Max. battery charging power: 12,000 W
- Asymmetric load support: 100% three-phase
- Backup switchover time: ≤ 20 ms
- Overload capability (off-grid): up to 200%
- Operating temperature: –25°C to +60°C
- Cooling method: natural convection
- Noise level: ≤ 29 dB
- Communication: RS485, built-in WLAN; Ethernet / 4G via optional dongle; EMMA support
- Dimensions (incl. brackets): 490 × 460 × 130 mm
- Weight: 21 kg
- Optimizer compatibility: SUN2000-450W-P2, SUN2000-600W-P, MERC-600W-PA0
